Travelling column milling machines

Second Hand Zayer 30 KCU 12000 with CNC Siemens 840. YOM 2008. Includes 5 heads, automatic head change, ATC 80 Tools, rotary table Bost, turning and milling tables Bost with Ø 2500 mm..Excellent Status. Can be inspected under power.

8 meters Soraluce used milling machine wth rototranslating machine
New in 2006 with CNC HEIDENHAIN TNC-530 HSCI
Table surface :7.500 x 5.000 mm
Automatic Head 45º , Horizontal Head and ISO 40 orthogocal head
Automatic change of head
ATC 40 tools. Internal coolant.
Rototranslating table 3000×3000 mm.

New in:2004
CNC: HEIDENHAIN TNC 530
Travels (X/Y/Z): 5.300/1.500/2.000 mm.
Table Surface :6.000 x 1.200 mm
Automatic Orthogonal Head 1º/1º
Internal Coolant 20 Bar
Chip conveyor

New in 2005. Heidenhain iTNC 530
Table size: 10.000×1.100 mm.
Travels (X/Y/Z): 8.500/1.200/2.000 mm.
Automatic head 2. 5º / 2. 5º
ATC 60 tools
Internal coolant
Tool and part touchprobes

YOM 2011. Heidenhain TNC 530
Travels (X/Y/Z): 5300/1500/2500 mm.
Roto-traversing table 2000×2000 mm. 360.000 Pos and travel 1500 mm.
Quill Ø 130 mm and Quill Travel 800 mm.
Milling Head ISO 0.0002º/2. 5º ISO 50
Boring Head SO 50
Automatic Head Changer

Columna móvil Lagun usada
Fabricada en 2008 con Heidenhain 530
Recorridos ( X/Y/Z): 6.000/1200/1500 mm.
Cabezal automático 2.5º/2.5º
Cargador de 60 herramientas
Refrigeración interna 20 Bar
Evacuador de viruta

Used Soraluce FL-6000. New in 2007.Heidenhain TNC 530, auto indexing head 2.5º / 2.5º, ATC 30 Tools, internal coolant, longitudinal and cross chip conveyor, tool probe, electrical cabinet coolant …

CNC Heidenhain TNC 530
New 2011
Automatic Head. Internal Coolant
ATC 60 Tools
Chip Conveyor
Rotary Table 2.000×2.000 mm.

Used traveling column milling machine Correa L30/28
New in :1997
CNC HEIDENHAIN TNC-426
Table Surface :4.600 x 1.000 mm
X Travel :2.800 mm
Y Travel :1.200 mm
Z Travel  :1.500 mm

Second Hand Zayer Travelling Column Milling Machine. Model 30 KCU 5000. Heidenhain TNC 430. Year 2003. Table: 5.000 X 2.000 mm. Travels ( X/Y/Z): 5.000 /1.250/ 2.000 mm. AutoIndex Head 45º 0.001º both in head and elbow. Direct Output Head, Automatic Head Changer. Internal Coolant 20 Bar. Chip Conveyor

CME mobile column with Juaristi MG-12 table
Manufactured in 2000 with CNC HEIDENHAIN TNC-430 M
Table surface: 5,000 x 2,000 mm.
Travels  (X/Y/Z): 8,000 / 1,500 / 2,500 mm.
Automatic head 45º ISO 50 2. 5º/2. 5th 3,000 rpm:
ATC 60 Positions
Internal cooling 20 Bar

Table Surface: 12.240 X 1.000 mm. Travels (X/Y/Z) : 10.450 /1.200/ 2.000 mm. Automatic Head: 2,5º – 2,5º. CNC HEIDENHAIN TNC 426. Longitudinal Chip Conveyor,.30 Tool ATC.

New in 2001. CNC HEIDENHAIN TNC-426
Table Surface:7.000 X 1.200 mm
Travels (X/Y/Z): 6.300/1.500/1.800 mm
Autoindex Head
ATC 30 Tools
Chip conveyor
Internal Coolant

New in 1998. CNC Heidenhain TNC 426CB
Travels(X/Y/Z): 6300/1500/2000 mm.
Auto Index Head 2.5º/2.5º
ATC 120 POs
Internal Coolant
Sprisin rotary table 1200×12000 mm turning 0.001º
Chip Conveyor

CNC SIEMENS 840. Year 2002. Table Surface:8.000 X 2.000 mm. Travels (X/Y/Z):7300/1500/2500 mm. Automatic Head: 2.5º-2.5º 24 Tools ATC. Internal Coolant. Longitudinal Chip Conveyor

CNC HEIDENHAIN TNC-530. Table Surface:9.700 X 1.200 mm. Travels (X/Y/Z): 8.408/1258/2005 mm. Automatic Head. 4 support cubes 1200 x1000 mm. Portable Wheel HEIDENHAIN HR-410. Main Engine Power:37 Kw.

Used ZAYER 30 KM 9000 Travelling Column Milling Machine. Year 2000. CNC Heidenhain TNC 430. Continuous Auto Indexing Head 0.001º/0.001º. Portable Handwheel Heidenhain HR 410.

CNC FAGOR 8055 MC. Table Surface: 4.590 X 1.000 mm. Travels(X/YZ):2.800/1200/1500. Rapid Traverse: 12.000 mm/min. Auto Indexing Head and Drect Exit Head. Portable Hand wheel. Year 1994

Used Correa L30/104. Year 2000. CNC Heidenhain TNC 426. Travels (X/Y/Z): 10.450/1.500/2.000 mm. Table Surface: 12.240×1.000 mm. AutoIndex Head 2.5º/2.5º. Chip Conveyor

Second Hand Zayer milling machine with CNC Heidenhain TNC-426. New in 1998. Autoindex Head with 2 Positions180º in Head and continuous (0.0001º) in elbow. Chip Conveyor. ATC 40 Tools

CME MQ 12000 milling machine with Heidenhain TNC 530.
Year 2011.
ATC 120 Tools
Longitudinal chip conveyor
Control panel with elevator at column side
Portable handwheel Heidenhain HR 410
Auto indexing ortogonal head: 0.1º- 0,1º.

CNC HEIDENHAIN TNC-430.
New in  2003.
Table Surface:10.000 X 1.100 mm.
Travels (X/Y/Z):8000/1200/1500 mm.
ATC 12 Tools.
Semi Automatic Head.
Longitudinal Chip Conveyor.

Table Surface: 10.000 X 1.100 mm. Travels (X/Y/Z): 8.000/1200/1500 mm. 30 Tools ATC. Automatic Head. Longitudinal Chip Conveyor. CNC HEIDENHAIN TNC-530. Portable Handwheel: HEIDENHAIN HR-410. Year 2003. 4º Axis Spirsin 81660/ D800.Electrospindle FAEMAT 200x200x250 28 Kw. Internal Cooling System
