Ibarmia

Ibarmia 5-axis machining center
Travels (X/Y/Z): 3,000x800x800 mm.
Table size: 3,600×850 mm.
Integrated rotary table Ø800 mm.
Tilting head range ± 105º
30 positions ATC
Internal coolant 20 Bar

Used Ibarmia 5-axis machining center
New in 2015. CNC Heidenhain iTNC 530
Travels(X/Y/Z): 1600/800/900 mm.
Tilting Head Range: ±105º
ATC 24 tools
Integrated 5th Axis Rotary Table D800 MR1
Part and tool touch probe

New in 2003 with  CNC FANUC 18i
Table surface :4.600 x 850 mm
Rotary table Ø 850 mm 360º 0,001º
Travels  (X/Y/Z) 4.000/800/860 mm.
Titling head  (B Axis) :±105º, 0,001º
ATC 40 Positions
Internal coolant 20 Bar

Second Hand Ibamia ZVH58 Extreme
New in 2014. CNC FANUC 31i B
Table Surface 3.600 x 1.050 mm.
Integrated Rotary Table Ø 800 mm.
Travels (Z/Y/Z) 3.000/1000/1100 mm
Valid Travel with 2 working sides 2 x 1.150 mm.
Range Tilting Head ±105º

Second Hand IBARMIA ZV50 L-1600 VMC
New in 2003 with Fanuc 18 iMD
Table Surface: 2.000×650 mm.
Travels: 1.600/600/800 mm.
ATC 30 Tools
Internal coolant
Refrigeración Interna

Second Hand Ibarmia VMC with  CNC Fanuc
New in 2014
ATC 24 Positions
2 Twin Divisors  (4th Axis )with Ø 400 mm. and travel 600 mm.
Chip Conveyor
Internal Coolant
Ready for EROWA system

HEIDENHAIN TNC-426. YOM: 1999. ATC 30 Tools. Double Chip Conveyor. Full Protection Guarding. Coolant through Tools 20 Bar. RENISAW OPM-60 Piece Touch Probe. Portable Handwheel.

Used Ibarmia Machining Center. Year 2003. Heidenhain TNC 530. Chip Conveyor. Automatic Tool Random 40 Tools . Portable Handwheel Heidenhain. Heidenhain Optic Rules

Used Ibarmia-50 Column Drilling in liquidation. Gears. Ø Maximum Drilling Steel: 50 mm. Coolant Unit: Soluble oil pump. Cross Table Dimensions: 780 x 300 mm. Horizontal Divisor Ø 450. Universal Chuck – 4 Jaws Ø 400 mm

CNC: HEIDENHAIN iTNC-530. Table Surface: Ø 400 mm. Travels (X/Y/Z) :600/428/410 mm. Travel A Axis: +120º- 120º / min.0,001º. Travel C Axix: 360º/min. 0,001º. Rapid Feed: 60.000 mm/min. 24 Tools ATC. Internal Cooling. Chip Conveyor.
