Used Machining Centre Ibarmia ZV 25 U600
Other available 5 Axis Machining Centers
DMG DMU 125 P 5 Axis
CNC: HEIDENHAIN TNC-426.New in 2006. Table Dimension:Ø 1.250 X 1.000 mm.Travels (X/Y/Z) :1.250/880/800 mm. Table Rotation (C Axis) :0,001 º (Continuous). ATC 30 Tools. Internal Coolant . Chip
DMG MORI DMU 75 monoBLOCK®
New in 2017. 3D CNC HEIDENHAIN TNC 640 Table surface: 800 x 650 mm. Tilting rotary table Ø650 mm 0.001º Travels (X/Y/Z): 750/650/560 mm. Spindle speed 20,000 rpm ATC 60 tools Internal
QUASER MV 204II U/10
Used Quaser 5 axis Machining center New in 2002. CNC HEIDENHAIN ITNC530 3 pallets Turning table (C Axis): 0.001º Travels (X/Y/Z): 700/590/480 mm. Titling spindle head range (A Axis):
IBARMIA ZVH58 – L3000
New in 2001 with a Heidenhain iTNC 530 control. Table area: 3,600 x 1,050 mm. Integrated rotary table: 1,000 mm diameter. Travels (Z/Y/Z): 3,000/1,000/860 mm Effective travel x 2 stations: 2
MAZAK VARIAXIS J600-5X
Second-hand Mazak 5-axis machining center Travels (X/Y/Z): 850/550/510 mm. Table tilting range (B axis): :210º (-120º +90º) 0.0001º Table rotation: 360º 0.0001º ATC 30 positions Chip
DMG DMU-160P
DMG machine center for 5-axis milling. New in 2002 with HEIDENHAIN iTNC-530 CNC Table: 1.500 x 1.250 mm. 0.001º (Continuous) Travel (X/Y/Z): 1,600/1,250/1,000 mm. Automatic head horizontal
DMG DMU-50 eVo linear
New in 2008 with HEIDENHAIN i-TNC 530 Rotary table 500×380 mm 0.001º ( ±360º) Travels (X/Y/Z) :500/450/400 mm Titling head :0º- 108º ATC 30 tools Internal coolant 40 bar with paper
DMG DMU 65 monoBLOCK®
Year 2012. HEIDENHAIN TNC 530 3D Table surface: 800 x 650 mm. Tilting rotary table Ø650 mm 0.001º Travels (X/Y/Z): 735/650/560 mm. Spindle speed 24,000 rpm ATC 60 tools Internal
Technical Features of this 5 axis machining center
| Table Dimension | Ø 400 mm. |
| Longitudinal Traverse (X Axis) | 600 mm. |
| Transversal Traverse (Y Axis) | 428 mm |
| Vertical Traverse (Z Axis) | 410 mm. |
| A Axis Stroke | +120º- 120º / min.0,001º |
| C Axis Stroke | 360º/min. 0,001º |
| Max. Working Feed | 60.000 mm/min |
| Taper | ISO-40 |
| Turning Speeds | 15.000 rpm |
| Main Motor Power | 35 /125 Kw. |
| Tools in Tool Charger | 24 Tool |
| Maximum Length of the Tool | 300 mm. |
| Cooling through tool 24 BAR | INCLUDED |
| Optical Rules | INCLUDED |
| Chip Conveyor | INCLUDED |
| Net Weight | 7.500 Kg. |
| Control | HEIDENHAIN iTNC-530 |
| Square Metres | 12m2 |
| Year Manufacture | 2002 |
| Machine Condition | VERY GOOD |
Detailed information of this 5 axis machining center
The Used Machining Centre Ibarmia ZV 25 U600 can be found in excellet status at the used metalworking machinery warehouse that Maquinaria Colás owns in Zaragoza (Spain). The used vertical machining centre has been totally retrofitted by our experienced team in the retrofitting and reconstruction of used machine tools. It’s a second use vertical machining centre with Heidenhain i TCN 530, perfectly equiped with ATC 30 positions, internal cooling, optics rules and chip conveyor. The vertical machining centre is ready to be inspected and delivered inmediately. diata.
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
