CORREA DIANA 20
Other available Bed Type Milling Machines
Anayak VH Plus 3000 MG-8 5x
5 Axis Anayak with integrated rotary table. New in 2010. CNC: HEIDENHAIN iTNC 530 Table 1.250 x 1.250 mm Travels ( X/Y/Z): 3.000/1.270/1.500 mm. ATC 40 tools Chip conveyor Internal
Correa CF25/25 – Used bed type milling machine
CNC Heidenhain TNC 530. New in 2008 Table Surface: 3.100 x 1.100 mm Travels:2.499/1.000/1.000 mm Autoindex head 0.1º/0.1º Longitudinal Chip Conveyor Internal
Zayer 20 KF-2000
CNC Heidenhain TNC 426 Table dimension :2.000 x 1.000 mm. Longitudinal travel (X Axis) :1.725 mm. Cross travel (Y Axis) :1.250 mm. Vertical travel (Z Axis) :1.000 mm. Hydraulic Tool
Soraluce TA35 Automatic
Soraluce bed type milling machine New in 2009 with CNC Heidenhain TNC 530 Travels (X/Y/Z): 3500/1000/1250 mm. Automatic Head 2.5º/2.5º ATC 20 Positions Chip Conveyor Internal
Technical Features of this Bed Type Milling Machine
Manufacturer | NICOLAS CORREA |
Model | DIANA-20 |
Year | 2008 |
CNC | HEIDENHAIN TNC-530 i |
Table Surface | 2.300 X 900 mm. |
Number of T Slots | 5 |
T Slots Dimensions | 22 mm. |
Longitudinal Traverse (X Axis) | 2.000 mm. |
Transversal Traverse (Y Axis) | 1.000 mm. |
Vertical Traverse (Z Axis) | 1.000 mm. |
Working Feeds (X/Y/Z) | 5-10.000 mm/min |
Rapid Traverse | 20.000 mm/min |
Head Type | Universal |
Taper | ISO 50 |
Turning Speeds | 20-4000 rpm |
Head Power | 22 Kw |
Hydraulic Tool Clamping System | INCLUDED |
EC Guarding | INCLUDED |
Carrying Load Table | 3.500 kg. |
Machine Weight | 14.000 kg. |
Machine Dimension | 6.114×5.070×2.803 mm |
Detailed information of this Bed Type Milling Machine
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
Sold. Request information about this type of machinery
