Used OKK VP-400
Other available Vertical Machining Centers
Johnford SV41 with pallet changer
Johnford VMC with pallet changer New in 2007 with FANUC 18i MC.2 Table: 1,200 x 600 mm Travel (X / Y / Z) :1,050 / 610 / 610 mm 20-tool ATC Internal coolant 20 Bar 2 longitudinal and 1
Johnford SV41
Johnford 3+2 axis machining center New in 2007 with HEIDENHAIN iTNC 530 Table: 1,200 x 600 mm Travels (X / Y / Z) :1,050 / 610 / 610 mm 20-tool ATC Golden Sun CNCT 321 rotary table
Used KONDIA A-10 VMC
Second Hand Kondia VMC New in 2006 CNC HEIDENHAIN 530 Table Surface :1.200 x 500 mm. Travels ( X/Y/Z) :1.000/500/610 mm. ATC 40 Tools Internal Coolant Chip
QUASER MV204CPL/12
Travels (X/Y/Z): 1,524/700/610 mm Table: 1,700 x 700 mm Taper: BT 40 BIG PLUS 30-position magazine 20 bar internal coolant 2 cross chip conveyor Longitudinal chip
Second Hand DMG DMF-260
New in 2011 with CNC SIEMENS SINUMERIC 840D Table dimmesion: 2,900 x 700 mm. Travels (X/Y/Z) :2,600/700/700 mm ATC 3o Internal coolant 40 Bar / 600 l Longitudinal chip
GORATU G INNOVA 15
New in 2004 with FAGOR 8055 MC Table surface: 1,725×650 mm. Travels (X/Y/Z): 1,5007700/700 mm. Spindle speed 10,000 rpm 24-tool
Used Kondia B-1050 VMC
Second Hand Kondia VMC with Heindenhain TNC530 Table Surface: 1.200 x 500 mm. Travels (X/Y/Z): 1.000/500/610 mm. Chip conveyor ATC 22 Tools Internal
Kondia A15
Used Kondia vertical machining center New in 2009 with HEIDENHAIN TNC 530 CNC Table Dimenssions: 1,550 x 700 mm. Travel (X/Y/Z axis): 1,500/700/700 mm. 40-tool ATC Internal coolant Chip
Technical Features of this Second Hand VMC
| Year | 2005 |
| CNC | Fanuc 160 is- MB |
| Table Size | 900 X 410 mm. |
| Longitudinal Traverse (X Axis) | 600 mm. |
| Cross Traverse (Y Axis) | 410 mm |
| Vertical Traverse (Z Axis) | 460 mm. |
| Max- Min Table to Head Distance | 150 a 610 mm |
| Rapid Traverse | 48 m/min |
| Max. Working Feed | 36 m/min |
| Taper | MAS BT-403 |
| Turning Speeds | 100-12.000 rpm |
| Main Motor Power | 22 /18,5 Kw. |
| Tools at ATC | 60 Tool |
| Tool Change Time (Chip /Chip) | 1,2 seg. |
| Max. Carrying Load Table | 500 Kg. |
| Coolant Through Tool 40 BAR | INCLUDED |
| NIKKEN CNC Z105 FA 4º Axis | INCLUDED |
| Optical Scales | INCLUDED |
| Cooled Spindle Axis | INCLUDED |
| Net Weight | 6.800 Kg. |
| Portable Handwheel | INCLUDED |
| Machine Dimension | 2900 x 2300 x 2800 mm. |
Detailed information of this Second Hand VMC
Used OKK VP-400 in our used machine tools warehouse in Zaragoza ( Spain ) Over 10.000 sq. metre warehouse full of used metalworking machinery in stock.
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
