Used LAGUN MC 1000 VMC
Technical Features of this Second Hand VMC
| Table Surface | 1.200X 500 mm |
| X axis Travel | 1.000 mm. |
| Y axis Travel | 500 mm |
| Z axis Travel | 510 mm. |
| Rapid Feed (X,Y,Z) | 12.000 mm/min |
| Max. Allowed Weight on Table | 750 kg. |
| Taper | ISO-40 |
| Head Speeds | 60-6.000 rpm. |
| Main Engine Power | 7,5 Kw. |
| ATC RANDOM | INCLUDED |
| Positions in ATC | 18 Pos. |
| 4th Axis SPIRSIN Ø 300 | INCLUDED |
| CNC | FAGOR 8050 |
| Machine Weight | 5.800 Kg. |
| New in | 1998 |
Detailed information of this Second Hand VMC
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
