Mazak VTC 200C-II VMC
Technical Features of this Second Hand VMC
| YOM | 2014 |
| CNC | MAZATROL FUSIÓN 640 M |
| Table Surface | 2.000 X 510 mm |
| Longitudinal Travel (X- Axis) | 1.660 mm. |
| Transversal Travel (Y-Axis) | 510 mm |
| Vertical Travel (Z- Axis) | 510 mm. |
| Min-Max. Distance Table to Nose Head | 180 – 690 mm. |
| Rapid Traverse (X,Y,Z Axis) | 36.000 mm/min |
| Max. Working Feed | 20.000 mm/min |
| Taper | CAT-40 |
| Spindle Speeds | 12.000 rpm. |
| Engine Power | 18,5 Kw. |
| ATC | 30 Tools |
| Rigid Tapping | INCLUDED |
| Length Tool Measure | INCLUDED |
| Chip conveyor right output dredger with drum | INCLUDED |
| Cooling through tool 15 BAR | INCLUDED |
| Central Separator ( 2 Working Areas) | INCLUDED |
| 2 Divisor KITAGAWA MR 200 +Tailstock | INCLUDED |
| Red Connection | INCLUDED |
| Hours On | 8.200 h. |
| Machine Weight | 9.100 Kg. |
Detailed information of this Second Hand VMC
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
