Used MAZAK FH-10800 Horizontal Machining Center

    • Centro Mecanizado Horizontal MAZAK FH-10800
    • Centro Mecanizado Horizontal MAZAK FH-10800 DE OCASION
    • Centro Mecanizado Horizontal MAZAK FH-10800 USADO

    Technical Features of this Used Horizontal Machining Center

    Year 2007
    CNC Mazatrol Fusion 640M
    Table Dimension 1.000 x 1.000 mm.
    Number of Tables 2
    Pallet Change Time 25 seg.
    Max. Ø Workpiece Rotation Ø 2.000 mm.
    Max. Workpiece Height 1.000 mm.
    Max. Workpiece Weight 3.000 Kg.
    Column Longitudinal Traverse X- Axis 1.700 mm.
    Cross Vertical Traverse Y- Axis 1.400 mm.
    Column Transversal Traverse Z- Axis 1.400 mm.
    Distance Table and Spindle Centre 100- 1500 mm.
    Distance Nose Spindle to Table Centre 200 – 1600 mm.
    Turning Speed 7.000 rpm
    Number of Ranges 2
    Taper BT 50
    Head Power 40 / 50 HP.
    Max. Torque 1.176 Nm.
    Rapid Traverse X, Y, Z Axis 40.000 mm/min
    Max. Working Feed X, Y, Z Axis 40.000 mm/min.
    ATC Positions 80
    Max. Tool Length 650 mm.
    Max. Tool Ø 260 mm.
    Max. Tool Weight 30 Kg.
    Tool Change Time (Tool to Tool) 1,8 Seg.
    Min. Pallet Indexing Angle 0,001º
    Coolant Tank Capacity 1.300 l.
    Coolant Through Tool 15 Bar.
    Ready For Coolant Through Tool 70 Bar INCLUDED
    Automatic Workpiece Measuring System  INCLUDED
    Chip Conveyor with outlet side   INCLUDED
    MZACC 2D High Speed Software  INCLUDED
    MAZATROL – ISO Programm Workpiece   INCLUDED
    Adaptive Feedrate Control   INCLUDED
    CNC Optional Package   INCLUDED
    Workpiece Touch Probe and MP-10 Centere   INCLUDED
    Cool Ball Screw (X,Y,Z)  INCLUDED
    Automatic Measuring Tool Length  INCLUDED
    Accuracy Placing Checking 0,005 mm.
    Accuracy Repetitively 0,0015 mm
    Total Power Required 70,8 Kw.
    POWER ON 8.218 h.
    Dimension (Length x Width x Hight) 6.900 x 4.353 x 3.527 mm.
    Machine Weight 30.800 Kg.

    Detailed information of this Used Horizontal Machining Center

    ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
    Technical specifications are not binding and may be modified without notice
