Doosan Ace HP5100

    • Centro de Mecanizado Horizontal Daewoo
    • Doosan Ace HP5100

    Technical Features of this Used Horizontal Machining Center

    Table Dimension 500 x 500 mm.
    Number of tables 2 Unidades/ Units.
    X Axis 850 mm.
    Y Axis 700 mm.
    Z Axis 750 mm.
    Pallet Index Degree Min. Angle 0,001º
    Number of Axis 4 Ejes/ Axis
    Pallet Index Time 90º 1,4 seg. /90º
    Max Tool Diameter Rotation Ø 800 mm.
    Piece Max. Height 500 mm.
    Piece Max. Weight 500 Kg.
    Spindle Speeds 14.000 rpm
    Taper BT 403
    Rapid Traverse 60.000 mm/min.
    Max. Working Feed 60.000 mm/min.
    Nº of Tool at Toolmagazine 40 Herr/ Tools.
    Tool Change Max. Time 1 Seg / Sec
    Pallet Change Max. Time 7,5 Seg./ Sec
    Main Engine Power 2 Kw
    Internal Coolant Through Tool INCLUDED
    Ball Screw Coolant (X,Y,Z) INCLUDED
    Light three colour, cycle light INCLUDED
    Chip Conveyor with bucket INCLUDED
    Wear and braking Tool Control INCLUDED
    Coolant INCLUDED
    Pallet Center Hole + block tooling INCLUDED
    4 Arnold Hydraulic Clamp INCLUDED
    Plenty of Tools and Accessories INCLUDED
    Machine Dimension 5380 x 2780 x 3025 mm.
    Total Power Required 68,1 Kva.
    Machine Weight 15.000 Kg
    Machine Condition SEMI-New

    Detailed information of this Used Horizontal Machining Center

    ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
    Technical specifications are not binding and may be modified without notice
