Used DMG DMU 80 MonoBLOCK
Other available 5 Axis Machining Centers
DMG DMU-160P
DMG machine center for 5-axis milling. New in 2002 with HEIDENHAIN iTNC-530 CNC Table: 1.500 x 1.250 mm. 0.001º (Continuous) Travel (X/Y/Z): 1,600/1,250/1,000 mm. Automatic head horizontal
DMG MORI DMU 75 monoBLOCK®
New in 2017. 3D CNC HEIDENHAIN TNC 640 Table surface: 800 x 650 mm. Tilting rotary table Ø650 mm 0.001º Travels (X/Y/Z): 750/650/560 mm. Spindle speed 20,000 rpm ATC 60 tools Internal
DMG DMU-50 eVo linear
New in 2008 with HEIDENHAIN i-TNC 530 Rotary table 500×380 mm 0.001º ( ±360º) Travels (X/Y/Z) :500/450/400 mm Titling head :0º- 108º ATC 30 tools Internal coolant 40 bar with paper
IBARMIA ZVH58 – L3000
New in 2001 with a Heidenhain iTNC 530 control. Table area: 3,600 x 1,050 mm. Integrated rotary table: 1,000 mm diameter. Travels (Z/Y/Z): 3,000/1,000/860 mm Effective travel x 2 stations: 2
DMG DMU 65 monoBLOCK®
Year 2012. HEIDENHAIN TNC 530 3D Table surface: 800 x 650 mm. Tilting rotary table Ø650 mm 0.001º Travels (X/Y/Z): 735/650/560 mm. Spindle speed 24,000 rpm ATC 60 tools Internal
DMG DMU 125 P 5 Axis
CNC: HEIDENHAIN TNC-426.New in 2006. Table Dimension:Ø 1.250 X 1.000 mm.Travels (X/Y/Z) :1.250/880/800 mm. Table Rotation (C Axis) :0,001 º (Continuous). ATC 30 Tools. Internal Coolant . Chip
MAZAK VARIAXIS J600-5X
Second-hand Mazak 5-axis machining center Travels (X/Y/Z): 850/550/510 mm. Table tilting range (B axis): :210º (-120º +90º) 0.0001º Table rotation: 360º 0.0001º ATC 30 positions Chip
QUASER MV 204II U/10
Used Quaser 5 axis Machining center New in 2002. CNC HEIDENHAIN ITNC530 3 pallets Turning table (C Axis): 0.001º Travels (X/Y/Z): 700/590/480 mm. Titling spindle head range (A Axis):
Technical Features of this 5 axis machining center
| Año | 2006 |
| CNC | HEIDENHAIN MILL PLUS IT |
| Dimensiones de la Mesa | 1.250 x 700 mm. |
| Curso Longitudinal ( Eje X) | 880 mm. |
| Curso Transversal (Eje Y) | 630 mm |
| Curso Vertical (Eje Z) | 630 mm. |
| Eje C en Mesa | CONTINUO |
| Giro de Cabezal Eje B | -91º / +12º CONTINUO |
| Avance rápido de los Ejes | 30.000 mm/min |
| Avance Máximo de Trabajo | 30.000 mm/min. |
| Tipo de cono husillo | SK-40 DIN 69871 |
| Gama de Revoluciones | 20-18000 rpm |
| Potencia Motor Principal | 19/28 Kw. |
| Cargador de Herramientas | INCLUIDO |
| Herramientas en Cargador | 32 Herr/Tools |
| Peso máximo sobre la Mesa | 800 Kg. |
| Refrigeración Interna 40 bar | INCLUIDO |
| Sonda de Medida de Pieza HEIDENHAIN TS 640 | INCLUIDO |
| Reglas Ópticas HEIDENHAIN | INCLUIDO |
| Transportador de Viruta | INCLUIDO |
| Volante Portátil | HEIDENHAIN HR-410 |
| Electromandrino Cabezal | Recién Reparado |
| 3D quickSET | INCLUIDO |
| Horas Encendido | 28.834 |
| Horas Husillo | 11.393 |
| Peso Neto | 9.500 Kg. |
| Herramientas y Accesorios | INCLUIDO |
| Estado de la Máquina | EXCELENTE |
Detailed information of this 5 axis machining center
