AWEA VP-2012
Technical Features of this Brige Type Milling Machine
| Manufacturer | AWEA |
| Model | VP 2012 |
| Year | 1998 |
| CNC | SIEMENS 810D |
| Table Surface | 2.200 x 1.100 mm |
| Max weight allowed on table | 3.500 kg. |
| Longitudinal travel (X Axis) | 2.000 mm |
| Cross travel (Y Axis | 1.200 mm |
| Vertical travel (Z Axis) | 760 mm |
| Distance between columns | 1.300 mm. |
| Rapid Traverse (X Axis) | 15 m/min. |
| Rapid Traverse (Y, Z Axis) | 12 m/min. |
| Taper | BT-50 |
| Main spindle speed | 5.000 r.p.m. |
| Main spindle power | 37 kVA |
| Speed ranges | 2 |
| Automatic tool changer (ATC) | INCLUDED |
| Positions in tool magazine | 30 |
| Internal coolant 20 BAR | INCLUDED |
| Coolant deposit capacity | 1000 l |
| Portable handwheel | INCLUDED |
| 2 longitudinal chip conveyor | INCLUDED |
| Cross chip conveyor | INCLUDED |
| Rigid taper | INCLUDED |
| Total power | 40 kVA |
| Machine Weight | 16.000 kg. |
| Large amount of tools and accessories | INCLUDED |
Detailed information of this Brige Type Milling Machine
Second-hand AWEA VP-2012 bridge type milling machine for sale due to total liquidation of die and mold manufacturing company. It is still at the original location (Valencia, Spain) where, always by appointment, it can be seen in operation.
Are you interested in this used AWEA VP-2012?
Then don’t miss the opportunity and find out about this bridge milling machine on liquidation sale. You can do so by calling to our phone number +34 976500624, writing to sales@maquinariacolas.com or filling out the quote request form.
Whether you just want to know the price or prefer more information, make a reservation or make an appointment to come see the milling machine in operation, we will be happy to help you.
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
