ZAYER MEMPHIS 10000-U
Technical Features of this Brige Type Milling Machine
| Manufacturer | ZAYER |
| Model | MEMPHIS 10.000-U |
| New in Month / Year | 2002 |
| CNC | HEIDENHAIN TNC-430M 9 EJES |
| Table | |
| Table Dimensions | 9.500 x 2.000 mm. |
| Max. Weight on Table | 20.000 kg |
| T slot number/width/ distance | 8/28/250 |
| Travels and feeds | |
| Longitudinal trave of the table l (X Axis) | 10.011 mm. |
| Ram cross travel (Y Axis) | 1.960 mm. |
| Vertical travel (Z Axis) | 1.112 mm. |
| Distance between columns | 2.850 mm. |
| Distance from table to main spindle nose in vertical position | 1.291 mm. |
| Distance from table to main spindle nose in horizontal position | 1.365 mm. |
| Working feed (X/Y/Z) | 20.000 mm/min. |
| Rapid Feed (X-Y-Z Axis) | 30.000 mm/min. |
| Main spindle | |
| Type | Automático 45º |
| Indexing positions | 360.0000 x 0.001º |
| Spindle taper | DIN 69871 AD 50 |
| Max spindle speed | 6.000 r.p.m. |
| Main spindle power | 37 kW |
| Automatic tool changer | |
| Manufacturer | AITEK |
| Type | Horizontal / vertical |
| Positions at tool magazine | 100 |
| Tool slank | ISO 7388-2 B50 |
| Max tool diameter with / without free adjacent positions | 250 /125 mm. |
| Double position tool change | INCLUIDO |
| Max tool length / weight | 400 mm / 25 kg |
| Other Equipment | |
| Coolant through the spindle | INCLUIDO |
| External coolant | INCLUIDO |
| JUMA+GAIN 150 coolant unit, with paper filter and magnetic separator, 1000 l capacity tank, one pump with a flow rate of 30 l/min, adjustable pressure up to 20 bar, another pump with a flow rate of 60 l/min, pres 2.5 bar. | INCLUIDO |
| 2 cross chip conveyor (front and back) | INCLUIDO |
| 2 operator panel ( front and back) | INCLUIDO |
| 2 portable handwheel (front and back) | HEIDENHAIN HR-410 |
| 2 cleaning guns (front and back) | INCLUIDO |
| Others | |
| Total Power | 103.40 kVA |
Detailed information of this Brige Type Milling Machine
Used ZAYER MEMPHIS 10000-U gantry milling machine for sale. It is available for immediate delivery from its original location (Germany), where it can be seen in operation for a limited time.
Do you want to know more about this used Zayer gantry milling machine?
Then don’t miss this opportunity and contact us. Whether you just want to know the price of this used ZAYER MEMPHIS 10000-U or would like more information and to see the machine in operation, we will be happy to help you.
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
