Used PINACHO TAURUS SK 260
Other available CNC Lathes
Gurutzpe A1600 CNC 2G x 4000
Fabricado en 2008 con FAGOR 8055 TC Distancia entre puntos :4.000 mm. Eje C y herramientas motorizadas. Eje Y Tipo torreta Sauter 4 POS Contrapunto con movimiento longitudinal por CNC Muy
Mori Seiki NLX 2500SY/700
Mori Seiki turning center new in 2011 C axis in spindle and sub spindle. Y Axis Maximum swing over bed: 590 mm. Driven Tools. High precision refrigeration Bar feeder and part
DAEWOO PUMA 2000-SY
New in 2003 with CNC FANUC 18i – T Max swing over bed/ carriage: 600/550 mm. Y Axis Travel: 100 (±50) mm. B Axis Travel: 580 mm. C axis 0.001º Driven turret positions
GEMINIS GHT4 720X2000
New in 2002 with FAGOR 8055 CNC Max. swing over bed/carriage: 720/470 mm. Main spindle hole diameter: 104 mm. Tailstock diameter: 100 mm Automatic 4-position turret 3 Jaw Universal
DOOSAN PUMA-700
Used Doosan CNC lathe ready for immediate delivery Year 2008. CNC Fanuc 21i TB Max swing over bed /carriage: 1,030/800 mm. Turret 12 positions 3 jaw-hydraulic chuck Ø 600 mm Tool
Geminis GHT4 720X3000
New in 2004 with FAGOR 8055 TC/B Maximum swing over bed/cross slide: 720/470 mm. C axis and driven tools Sauter turret 8 positions SHW Autoblock 315 BH Self-Centering 3-Jaw Chuck Hydraulic
Technical Features of this Second Hand CNC Lathe
| Year | 2008 |
| CNC | FAGOR 8050 TC |
| Diam. Max. Over Bed | 530 mm. |
| Diam. Max. Longitudinal Carriage | 475 mm. |
| Diam. Max. Transversal Carriage | 315 mm. |
| Centres Height | 260 mm |
| Distance Between Centres | 1.500 mm. |
| Bed Width | 350 mm. |
| Main Spindle Bore Ø | 80 mm. |
| Rapid Traverse X Axis | 10.000 mm/min |
| Rapid Traverse Z Axis | 10.000 mm/min |
| Head Turning Speeds | 0-2.500 rpm |
| Head Automatic Range | 1 |
| Main Motor Power | 11 Kw. |
| Spindle Nose | ASA B5,9 |
| Tailstock Quill Ø | 82 mm |
| Hydraulic Tailstock Quill Travel | 235 mm |
| Tailstock Morse Taper | Morse 5 |
| Turret Automatic Change Duplomatic 8 Pos. | INCLUDED |
| Universal Chuck – 3 Jaws Ø 250 | INCLUDED |
| Complete Rear Protection | INCLUDED. |
| 2 Handwheels at Control Pad | INCLUDED. |
| Machine Dimensions | 5.435 x 1.985 mm |
| Machine Weight | 3.500 Kg. |
| Total Power Required | 20 Kw. |
Detailed information of this Second Hand CNC Lathe
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
