Used DMG DMU 60 MonoBLOCK
Other available 5 Axis Machining Centers
QUASER MV 204II U/10
Used Quaser 5 axis Machining center New in 2002. CNC HEIDENHAIN ITNC530 3 pallets Turning table (C Axis): 0.001º Travels (X/Y/Z): 700/590/480 mm. Titling spindle head range (A Axis):
MAKINO DA 300
5-axis high-speed Makino center Manufactured in 2016 with CNC FANUC 31Is-B 340 x 300 mm continuous 360º turning table Table inclination: :150º (+30º-120º) Travels (X/Y/Z): 450/620/500
FANUC Robodrill alpha D21LIB5 5ax
Semi-new 5-axis machining center FANUC New in 2017 with CNC FANUC 31i-B5 Table size: 850×410 mm. Rotary Table Nikken 5AX-DD200BF2 X/Y/Z axis travel: 700x400x330 mm. Internal Coolant 25
Ibarmia ZVH55-L3000
Ibarmia 5-axis machining center Travels (X/Y/Z): 3,000x800x800 mm. Table size: 3,600×850 mm. Integrated rotary table Ø800 mm. Tilting head range ± 105º 40 positions ATC Internal coolant
Technical Features of this 5 Axis Machining Centers
New in | 2006 |
CNC | Heidenhain TNC 530i |
Table Dimension | 1.000 x 600 mm. |
Longitudinal Traverse | 730 mm. |
Cross Traverse | 560 mm |
Vertical Traverse | 560 mm. |
Ø C Axis in Table | Ø 600 mm. |
C Axis in Table | CONTINUOUS |
B Axis Turning Head | -30º / +120º CONTINUOUS |
Rapid Traverse | 30.000 mm/min |
Max. Working Feed | 30.000 mm/min. |
Taper | SK-40 DIN 69871 |
Turning Speeds | 20-12000 rpm |
Main Motor Power | 15 Kw. |
ATC | INCLUDED |
Tools at Tool Charger | 24 |
Table Max. Carrying Load | 700 Kg. |
HEIDENHAIN Optical Rules | INCLUDED |
Chip Conveyor | INCLUDED |
Portable Handwheel | HEIDENHAIN HR-410 |
3D quickSET* | INCLUDED |
Spindle On | 5.740 Horas |
Net Weight | 6.500 Kg. |
Machine Condition | EXCELLENT |
Detailed information of this 5 Axis Machining Centers
This Used DMU 60 MonoBLOCK can be found in excellent conditions at our used metal working machinery warehouse in Zaragoza (Spain) Reviewed and ready for immediate inspection and delivery.
Call us now for more information and prices of this second hand 5 axis machining center. We will be happy to help!
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
Sold. Request information about this type of machinery
