GEMINS GHT-5 G2 1000X8000 CNC Lathe

    Used GEMINS GHT-5 G2 1000X8000 CNC Lathe
    Request information on similar machines

    Other available CNC Lathes

    Used Mori Seiki NLX2500700SY turning center for sale

    Mori Seiki NLX 2500SY/700

    Mori Seiki turning center new in 2011 C axis in spindle and sub spindle. Y Axis Maximum swing over bed: 590 mm. Driven Tools. High precision refrigeration Bar feeder and part

    CNC Lathe Mori Seiki NT4250-DCG

    MORI SEIKI NT 4250-DCG 1500S

    Second-hand turning and milling center New in 2008 with MSX-701 III CNC Spindle 1, spindle 2 and too spindle C axis in Spindle 1 and 2 Y Axis. Hydraulic steady rest SMW Autoblock

    GEMINIS GHT5 G2 1000x4000

    GEMINIS GHT5-G2 1000×4000

    Used Geminis lathe with 4 meters between centers New in 2007 with CNC:FAGOR 8055 TC/C SAUTER turret 300×300 with 4 positions C axis and driven tools Equipped with tools and

    Daewoo Puma CNC Lathe

    DAEWOO PUMA 2000-SY

    New in 2003 with CNC FANUC 18i – T Max swing over bed/ carriage:  600/550 mm. Y Axis Travel: 100 (±50) mm. B Axis Travel: 580 mm. C axis 0.001º Driven turret positions

    GEMINIS GHT-5 G2 1000 X 9000 - Used

    GEMINIS GHT5 G2 1000 x 9000

    Manufactured in 2007 with CNC HEIDENHAIN 4110 MANUAL PLUS ØMax. turning over bed/carriage: 1,000/680 mm. C axis and driven tools VDI 50 turret (Ø 470 mm) with 8 positions Distance between

    Gurutzpe A 1000 / 3 x 4000

    Gurutzpe A 1000/3 x 4000

    4 meter used  Gurutzpe CNC Lathe New in 2003. CNC FAGOR 8055 Max swing over bed :800 mm. C Axis and driven tools Turret SAUTER VDI 50 12 positions Chip

    Géminis GHT-4 720X3000

    Geminis GHT4 720X3000

    New in 2004 with FAGOR 8055 TC/B Maximum swing over bed/cross slide: 720/470 mm. C axis and driven tools Sauter turret 8 positions SHW Autoblock 315 BH Self-Centering 3-Jaw Chuck Hydraulic

    Technical Features of this Second Hand CNC Lathe

    New in 2006
    CNC Fagor 8055 TC
    Max. Swing Over Bed Ø 1.000 mm.
    Max. Swing Ø 1.000 mm.
    Max Swing Over Cross Slide Ø 680 mm.
    Distance Between Centres 8.000 mm.
    Rapid Feed X, Z Axis 8 m/min
    Turning Speeds 0-1400 rpm
    Spindle Automatic Ranges 4 Ranges
    Main Spindle Motor Power 37 Kw.
    Spindle Nose DIN-55026-B11
    Turret Positions 4 posiciones/ positions
    Turret Type SAUTER 300 X 300
    Chuck with 4 Indep. Hard Jaws Ø900 mm . INCLUDED
    2 Steady Rest 3 Supports Ø 430 mm INCLUDED
    Chuck Protection INCLUDED
    Complete Rear Protection INCLUDED
    Longitudinal Chip Conveyor INCLUDED
    Quill Travel 104 mm.
    Ø Tailstock Quill 140 mm
    Tailstock Quill Traverse 300 mm
    Max.Weight Between Centres (1 Steady) 6.200 Kg.
    Piece Max. Weight Between Centres 4.800 Kg.
    Machine Weight 16 Tn.
    Total Power Required 45 Kw.

    Detailed information of this Second Hand CNC Lathe

    Used GEMINS GHT-5 G2 1000X8000 CNC Lathe for sale at our second-hand lathe warheouse in Zaragoza.

    We have a permanent stock of used machine tools in continuous change A space of over 12,000 sqm available to our customers so that they can always find the machine they need at a price they can afford.

    Manufactured in 2006 with solid and durable architecture, this used GEMINS GHT-5 G2 1000X8000 CNC Lathe has a Fagor 8055 TC CNC installed that offers high response speed, reliability, and maximum precision. In addition, its versatility and ease of use and programming will become the best ally of your staff.

    Among the equipment included are a chuck with 4 Independent Claws Ø 900 mm, 2 steady rests with 3 jaws of Ø 430 mm, chuck protection, complete rear protection and longitudinal chip evacuator.

    Do you want to buy this used Geminis lathe?

    Then do no hesitate and contact us. Get all the information you need as well as budget.

    Call us at +34976500624, write to  sales@maquinariacolas.com or fill in the form that appears at the bottom of the page. We will contact you.

    If you prefer, come and visit us. You will see the usedGEMINS GHT-5 G2 1000X8000 CNC Lathe  under power. We are delighted to welcome you to our company.

    ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
    Technical specifications are not binding and may be modified without notice
