Geminis GTH4 620×3000 Used CNC Lathe
Other available CNC Lathes
MORI SEIKI NL 3000 / 3000
Manufactured in 2008 with MORI SEIKI MSX-850III CNC Max. swing over bed / carriage: 995 / 825 mm Spindle bore: 105 mm 12-position turret SCHUNK THW hydraulic chuck (Ø400 mm) SHW hydraulic
GURUTZPE A1200 4G CNC x 6000
New in 2008 CNC: FAGOR 8055 TC Maximum swing over bed/carriage: 1,200/1,000 mm C-axis + live tooling 4-jaw independent chuck (Ø 800 mm) 3 fixed steady rests and 2 Morari hydraulic
DAEWOO PUMA 2000-SY
New in 2003 with CNC FANUC 18i – T Max swing over bed/ carriage: 600/550 mm. Y Axis Travel: 100 (±50) mm. B Axis Travel: 580 mm. C axis 0.001º Driven turret positions
GEMINIS GHT6-G2 1300 x 3000
Year: 2007. FAGOR 8055 TC/C CNC Max. swing over bed / carriage: 1,300/940 mm Distance between centers: 3,000 mm C-axis and live tooling 8-position VDI 50 turret Ø 900 mm universal 3-jaw
Geminis GHT4 720X3000
3-meter used CNC lathe New in 1999 CNC FAGOR 8055 TC/B Swing over bed/carriage: 720 / 470 mm Spindle bore diameter: 92 mm Duplomatic VDI 40 8-position turret 3-jaw self-centering
Pinacho Rhino SK/425
New in 2005 with GE Fanuc Series 21i-T CNC Distance between centers: 5,000 mm Max swing over bed/carriage: 850/560 mm 8-position automatic turret Tailstock with hydraulic quill stroke 3-jaw
Mori Seiki NLX 2500SY/700
Mori Seiki turning center new in 2011 C axis in spindle and sub spindle. Y Axis Maximum swing over bed: 590 mm. Driven Tools. High precision refrigeration Bar feeder and part
GEMINIS GHT6 G4 1,300 x 5,000
New in 2008. CNC Fagor 8055TC Maximum swing over bed / carriage: 1300/1000 mm DIN 55026-11 spindle nose with 104 mm bar capacity SAUTER 300×300 4-position automatic turret Tailstock quill
Technical Features of this Second Hand CNC Lathe
| Max. Swing Over Bed Max. Ø | 620 mm. |
| Max. Swing Ø | 620 mm. |
| Max Swing Over Cross Slide Ø | 370 mm. |
| Distance between Centres | 3.000 mm. |
| Rapid Traverse X Axis | 8 m/min |
| Rapid Traverse Z Axis | 8 m/min |
| Turning Speed | 0-1600 |
| Spindle Automatic Ranges | 2 Ranges |
| Main Motor Power | 20,5 Kw. |
| Spindle Nose | DIN-55027-11 |
| Turret Stations | 4 Pos-Automátic. |
| Automatic Square Turret Type | SAUTER 240 x 240 |
| Quill Travel | 104 mm. |
| Ø Tailstock Quill | 100 mm |
| Tailstock Quill Traverse | 200 mm |
| Tailstock Quill Morse | 6 |
| Year | 2007 |
| CNC | Fanuc 21i TB |
| FANUC Portable Handwheel | INCLUDED |
| Back Protection | INCLUDED |
| Hydraulic Chuck Ø 300 mm | INCLUDED |
| Internal Coolant Through Tool | INCLUDED |
| High Pressure Pump 15 Bar | INCLUDED |
| Longitudinal Chip Conveyor | INCLUDED |
| Fix SteadyRest 50/220 | INCLUDED |
| Full Equipped with Tools | INCLUDED |
| Machine Dimensions | 5.600 x 2.300 mm |
| Machine Weight | 6.500 Kg. |
| Total Power Required | 28 Kw. |
| Machine Condition | GOOD |
Detailed information of this Second Hand CNC Lathe
This Geminis GTH4 620×3000 Used CNC Lathe was new in 2007 and can be found in excellent status at Maquinaria Colás in Zaragoza (Spain) Includes: CNC Fanuc 21i TB FANUC portable Handwheel, back protection, hydraulic chuck Ø 300 mm, internal coolant through tool, high pressure pump 15 Bar, longitudinal chip conveyor, fix steady rest 50/220. The Geminis GTH4 620×3000 Used CNC Lathe is Equipped with Tools and Accessories
If you are looking for an used CNC lathe don’t hesitate and contact us. We have a wide selection of used industrial machinery reviewed and ready to be sold. You can get more info of this or any other machine calling us at our customer service telephone +34976500624 or via the contact form appearing at the end of the page. We will be glad to assist you.
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
