Used CMZ TL25 AMS Lathe
Technical Features of this Second Hand CNC Lathe
| CNC | FANUC 18i- TB |
| Year | 2005 |
| Power On | 9021 |
| Swing over Bed | 685 mm. |
| Swing over Carriage | 510 mm. |
| Máximum Turning Diameter | 430 mm. |
| Distance Between Centres | 522 mm. |
| X Travel | 240 mm. |
| Z Travel | 640 mm. |
| B Travel | 520 mm. |
| Rapid Feed | X 18.000 mm/min |
| Rapid Feed | Z 24.000 mm/min. |
| Rapid Feed B 24.000 mm/min. | |
| Bar Cross | 66 mm. |
| Spindle Cross | 250 mm. |
| Subspindle Cross | 130 mm |
| Spindle Power | 35 KW |
| Subspindle Power | 15 KW |
| Spindle Max. Speed | 4.000 r.p.m. |
| SubSpindle Max. Speed | 5.000 r.p.m. |
| Change Time | 180º- 0.5s. |
| Stations Turret | 12 |
| Total Power 50 | KVA |
| Machine Dimensions | 2322x1603x1800 mm |
| Machine Weight | 5.700 Kg. |
| EQUIPMENT | |
| B Axis | INCLUDED |
| C Axis | INCLUDED |
| Driven Tools | INCLUDED |
| Nr of Station Driven Tools | 12 |
| Speeds of Driven Tools | 4.000 rpm |
| Power Driven Tools | 16 KW |
| Side Chip Conveyor | INCLUDED |
| Piece Dustpan | INCLUDED |
| Hidden Preseter. INCLUDED | |
| Head Oil Coolant | INCLUDED |
| Ready for Bar Feeder | INCLUDED |
| Piece Conveyor Belt | INCLUDED |
| Double Pedal for Spindle and Subspindle | INCLUDED |
| 1 Radial Live Tool Holder | INCLUDED |
| 1 Axial Live Tool Holder | INCLUDED |
| 1 Angular Live Tool Holder | INCLUDED |
| Collet Set for Live Tools | INCLUDED |
| SMW Autoblock Collet Holder + Set of Collets | INCLUDED |
| Sarralle Metal Cabinet | INCLUDED |
| Big Cuantity of Tool Holder | INCLUDED |
Detailed information of this Second Hand CNC Lathe
This CMZ TL25 AMS Lathe with B, C and driven tools is available for sale at our used machine tools warehouse in Zaragoza ( Spain) New in 2005. CNC FANUC 18i- TB.
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
