Planer type Boring-Milling centre Juaristi TS 3 5 Axis

    Second Hand Boring Machine Juaristi TS3 5 Axis
    Request information on similar machines

    Other available Boring machines

    Used Johnford BMC-110

    Johnford BMC 110

    New in 2012 with CNC FAGOR 8055-MC Table: 1,400 x 1,600 mm continuous  (0.001º) Travel (X/Y/Z axis): 2,000/1,800/1,600 mm. Quil diameter: 110 mm. 60-tool ATC Internal coolant 20

    Used Juaristi TS.3 MG-12 boring and milling center

    Juaristi TS 3-MG 12

    Juaristi TS3 milling and boring center Manufactured in 2009 with CNC Heidenhain TNC 530 Juaristi MG-12 rotary table 2,000 x 2,500 mm. Automatic bi-rotative milling head 2.5º / 2.5º Boring

    Technical Features of this Boring Machine

    Table Surface 2000 X 2000 mm.
    Quill Diameter 130 mm.
    Table Longitudinal Traverse (X Axis) 4.000 mm.
    Column Transversal Traverse (W Axis) 1.925 mm.
    Vertical Traverse (Y Axis) 2.500 mm.
    Quill Exit Traverse (Z Axis) 800 mm.
    Table Rotation (B Axis) Continuous (0.001º)
    Automatic Tool Charger – 40 tools INCLUDED
    Chip Conveyor INCLUDED
    Year 2001 CNC HEIDENHAIN TNC 426
    M&G Piece Measure Probe INCLUDED
    Tool External Coolant INCLUDED
    Tool Internal Coolant INCLUDED
    Protection Guarding Charger Area – CNC Area INCLUDED
    Main Axis Orientation INCLUDED
    Rapid Traverse 12.000 mm/min
    Head Internal Taper ISO 50 DIN 69871/1-B
    Speed Range  2 Ranges
    Turning Speeds 0-2.500 rpm
    Head Power 37 Kw.
    Carrying Load Table MG 12 9.000 kg.
    Machine Weight 45.000 kg.
    Portable Handwheel HEIDENHAIN HR-410
    Universal Head INCLUDED
    Extended Head INCLUDED
    Machine Colour RAL 7035 / RAL 5015
    Machine Condition Excellent

    Detailed information of this Boring Machine

    This Planer type Boring-Milling centre Juaristi TS 3 5 Axis with Heidenhain TNC-426 was built in 2001 and has been recently reconstructed by our staff, a complete team of experts in reconstructing milling an boring machines. The machine can be found in our 6000 sq. meter used metalworking machinery warehouse in Zaragoza.  It has a central headstock with a very robust cast iron structure suitable for large components machining.

    This machine concept with the rotary table incorporated, allows the machining of extra big parts.

    The guides or this Planer type Boring-Milling centre Juaristi TS 3 5 Axis are hardened and ground, large and prismatic, with counterguides in special antifriction material, SKC.

    The headstock is centered in the column, with box guides in the front and linear guides in the rear side, achieving a perfectly guided assembly, capable of withstanding the more demanding cutting operations without any vibration even in the toughest conditions.

    Continuous development in new accessories and its adaptation, has come out in a machining centre with extraordinary high performance, accuracy and heavy duty cutting capacity.

    If you need more information about thisPlaner type Boring-Milling centre Juaristi TS 3 5 Axis you only have to contact us using the form at the end of the page or call to our customer service telephone where we will be happy to help you with any infomation y9u may need.

    Technical specifications are not binding and may be modified without notice
