FANUC Robodrill alpha D21LIB5 5ax
Other available 5 Axis Machining Centers
DMG DMU-50 eVo linear
New in 2008 with HEIDENHAIN i-TNC 530 Rotary table 500×380 mm 0.001º ( ±360º) Travels (X/Y/Z) :500/450/400 mm Titling head :0º- 108º ATC 30 tools Internal coolant 40 bar with paper
IBARMIA ZVH58 – L3000
New in 2001 with a Heidenhain iTNC 530 control. Table area: 3,600 x 1,050 mm. Integrated rotary table: 1,000 mm diameter. Travels (Z/Y/Z): 3,000/1,000/860 mm Effective travel x 2 stations: 2
QUASER MV 204II U/10
Used Quaser 5 axis Machining center New in 2002. CNC HEIDENHAIN ITNC530 3 pallets Turning table (C Axis): 0.001º Travels (X/Y/Z): 700/590/480 mm. Titling spindle head range (A Axis):
DMG MORI DMU 75 monoBLOCK®
New in 2017. 3D CNC HEIDENHAIN TNC 640 Table surface: 800 x 650 mm. Tilting rotary table Ø650 mm 0.001º Travels (X/Y/Z): 750/650/560 mm. Spindle speed 20,000 rpm ATC 60 tools Internal
DMG DMU 125 P 5 Axis
CNC: HEIDENHAIN TNC-426.New in 2006. Table Dimension:Ø 1.250 X 1.000 mm.Travels (X/Y/Z) :1.250/880/800 mm. Table Rotation (C Axis) :0,001 º (Continuous). ATC 30 Tools. Internal Coolant . Chip
DMG DMU-160P
DMG machine center for 5-axis milling. New in 2002 with HEIDENHAIN iTNC-530 CNC Table: 1.500 x 1.250 mm. 0.001º (Continuous) Travel (X/Y/Z): 1,600/1,250/1,000 mm. Automatic head horizontal
DMG DMU 65 monoBLOCK®
Year 2012. HEIDENHAIN TNC 530 3D Table surface: 800 x 650 mm. Tilting rotary table Ø650 mm 0.001º Travels (X/Y/Z): 735/650/560 mm. Spindle speed 24,000 rpm ATC 60 tools Internal
MAZAK VARIAXIS J600-5X
Second-hand Mazak 5-axis machining center Travels (X/Y/Z): 850/550/510 mm. Table tilting range (B axis): :210º (-120º +90º) 0.0001º Table rotation: 360º 0.0001º ATC 30 positions Chip
Technical Features of this 5 axis machining center
| CNC | FANUC 31i-B5 | |
| New in | 2017 | |
| Table size | 850×410 mm. | |
| Max weight allowed of table | 300 kg | |
| Rotary table | Nikken 5AX-DD200BF2 | |
| X/Y/Z travels | 700x400x330 mm. | |
| Max tool weight | 3 kg | |
| Max tool length | 200 mm | |
| Tip distance from the head to the table | 250-580 mm | |
| Spindle speed | 24.000 rpm | |
| Rapid feed all axis | 54 m/min | |
| Taper | BT-30 | |
| Compressed air consumption | 150 L/min, 0.35-0.55 Mpa | |
| ATC | INCLUDED | |
| Positions in ATC | 21 | |
| Double contact system | INCLUDED | |
| Internal Coolant 25 Bar | INCLUDED | |
| Deposit Capacity | 250 l | INCLUDED |
| Deublin joint for coolant and air | INCLUDED | |
| Renishaw OTS probe kit for tool measurement + OMP-400 for centering and verification of part and calibration 5 axes | INCLUDED | |
| WS1000 FOX Vacuum Cleaner | INCLUDED |
Detailed information of this 5 axis machining center
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
