CMZ TC-25Y-800 CNC Lathe
Technical Features of this Second Hand CNC Lathe
| Model | TC25Y-800 |
| Year | 2012 |
| CNC | FANUC 32i MODEL B |
| C Axis and Driven Tools | INCLUDED |
| Y Axis | INCLUDED |
| Distance between chuck and tailstock | 898 mm. |
| Ø Swing over Bed | 920 mm. |
| Ø Max.Turning over Carriage | 745 mm |
| X Travel | 315 mm. |
| Z Travel | 800 mm. |
| Y Travel | +80 -60 |
| Rapid Feeds (X, Z Axis) | 30 m/min |
| Rapid Feed (Y Axis) | 15 m/min, |
| Axis Acceleration | 1g |
| Max Speed of the Head | 4.000 rpm |
| Ø Spindle Bar Diameter | 66 mm. |
| Chuck Bore Ø | 66 mm. |
| Spindle Max. Power | 35 kW |
| Number of positions of Driven tools | 16 |
| Driven Tools Speed | 4.000 rpm |
| Max Power Driven Tools | 16 kW |
| Max Torque Dirven Tools | 75 Nm |
| Chuck SHUNK 260-81 | INCLUDED |
| Rapid Change of Jaws in Hydraulic Chuck | INCLUDED |
| 2nd High Pressure Coolant Pump (15 Bar, 55 l/min) | INCLUDED |
| 2 Axial Diven Tool Holder | INCLUDED |
| 2 Radial Driven Tool Holder | INCLUDED |
| Tool Presetter | INCLUDED |
| Coolant Tank Capacity | 300 l. |
| Installed Power | 45 KVA |
| Machine Weight | 7.200 Kg. |
| Machine Dimensions | 2.803×2.020×2.236 mm,. |
Detailed information of this Second Hand CNC Lathe
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
Other available CNC Lathes
HYUNDAI KIA SKT-400LMC
Used HYUNDAI – KIA turning center New in 2008 CNC FANUC 21 i TB Distance between centers :2.110 mm. Max Turning Ø :570 mm. C Axis and Driven Tools Turret 12 Positions 2 Radial and 2
DOOSAN PUMA 2000SY CNC Lathe
Second Hand Turning Center with main spindle, sub-spindle both with C Axis Driven tools Y Axis New in 2007. CNC Fanuc 18I MB Bar Feeder TNS
GEMINIS GHT6-G2 8000×1300
8-meter Geminis turning center New in 2007 with CNC SIEMENS 810 D Distance between centers: 8,000 mm. 4-position automatic turret Longitudinal Chip Conveyor Chuck 4 Independent Hard Jaws Ø
GURUTZPE A-1400 x 5000 2G
