Used MAZAK INTEGREX 100-IIIST CNC Lathe

    • MAZAK INTEGREX 100-IIIST
    • TORNO MAZAK INTEGREX DE OCASION
    • MAZAK INTEGREX 100 USADO
    • MAZAK INTEGREX 100 DE SEGUNDA MANO
    • TORNO MAZAK INTERGREX USADO

    Technical Features of this Second Hand CNC Lathe

    Year 2005-11
    CNC MAZATROL 640 MT PRO
    Swing over Cross Slide 545 mm.
    Max. Machining Ø Milling Head 545 mm.
    Max. Machining Ø Lower Turret 400 mm.
    Max. Machining Length 753 mm.
    X Axis Traverse 410 mm.
    Z Axis Traverse 805 mm.
    Y Axis Traverse 140 mm.
    X2 Axis Traverse 220 mm.
    Z2 Axis Traverse 780 mm.
    W Axis Traverse 795 mm.
    Rapid feed X/Z Axis 30/33 m/min.
    Rapid feed X2/Z2/ Axis 30/33 m/min.
    Rapid feed Y Axis 26 m/min
    Rapid feed W Axis 30 m/min.
    Main Spindle Trough-Hole Ø 61 mm
    Sub Spindle Trough-Hole Ø 61 mm
    Main Spindle Speed Ranges 35 – 6.000 rpm.
    Sub Spindle Speed Ranges 35 – 6.000 rpm
    Main Spindle motor power 11 kW
    Sub Spindle motor power 11 kW
    Main Spindle Maximum Torque 16.4 kgf
    Sub-spindle Maximum Torque 16.4 kgf
    Upper Turret Stations (Capto Type) 40
    Lower Turret Stations 8
    C Axis in main Spindle INCLUDED
    C Axis in sub Spindle INCLUDED
    C Axis index 0.001 Degrees
    Driven Tools INCLUDED
    Spindle Chuck KITAGAWA B-206 Ø 170 mm
    Sub Spindle Chuck KITAGAWA B-206 Ø 170 mm
    Tool pre-setter INCLUDED
    Cutting oil high pressure pump INCLUDED
    Coolant tank capacity 290 l.
    Chip Conveyor INCLUDED
    Machine Weight 7.600 kg.

    Detailed information of this Second Hand CNC Lathe

    ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
    Technical specifications are not binding and may be modified without notice
