Used Lathe Gurutzpe Super M 350 3000
Other available Conventional lathes
Ravensburg P 30
Used Ravensburg facing lathe for sale Max swing over bed / pocket: 3,040/4,300 mm. Bar Ø: 140 mm. HEIDENHAIN 4-axis DRO 8 independent jaw chuck Ø 2,500 mm. Maximum weight allowed: 25,000
Technical Features of this Conventional lathes
Distancia entre Puntos | 3.000 mm |
Diámetro Mecanizable sobre Bancada | 750 mm |
Diámetro Mecanizable sobre Carro | 520 mm. |
Diámetro Mecanizable Sobre Escote | 1.050 mm |
Recorrido Carro Longitudinal | 3.000 mm. |
Recorrido Carro Transversal | 380 mm. |
Gama de Revoluciones de la Máquina | 16 – 1.250 rpm. |
Nº de Velocidades | 18 |
Velocidades Potencia motor principal | 12,5 H.P. |
Peso máquina | 4.000 Kg |
Dimensiones | 5.200×1.500×1.500 mm |
Luneta Fija Ø 250 | INCLUIDO |
Plato 4 Garras Independietes | Ø 500 INCLUIDO |
Plato 3 Garras Universal | Ø 300 INCLUIDO |
Torreta de Cambio Rápido | INCLUIDO |
Visualización de Ejes | MITUTOYO (2 Ejes) INCLUIDO |
Estado de la Máquina | MUY BUENO |
Detailed information of this Conventional lathes
This used lathe Gurutzpe Super M 350*3000 can be found in excellen conditions at the used machine tools warehouse in Spain we own. We offer top quality CNC and Conventional machine tools. Call us for more information and pricing.
Please fill the contact form below and we will inform you!!
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
Last update: 04/11/24
Sold. Request information about this type of machinery
