NHX-6300 DMG – MORI

    • Centro Horizontal DMG-Mori de segunda mano
    • DMG MORI CNC CELOS CON FANUC
    • DMG – MORI NHX-6300
    • DMG-MORI NHX-6300 de ocasión
    • DMG-MORI NHX-6300 de segunda mano

    Technical Features of this Used Horizontal Machining Center

    Manufacturer DMG-MORI
    Model NHX-6300
    Year 2018
    CNC Unit FANUC FS-31IB
    CNC Operation Panel CELOS ErgoLine
    CNC Screen Touch Screen 21.5”
    NC-Rotary Table with pallet changer INCLUDED
    Pallet Dimensions 630 x 630 mm.
    Max allowed weight on pallet 1.500 kg.
    Pallet Units 2
    Rotary Table Index ( B Axis) 360.000×0.001º
    Distance pallet surface to spindle center 50-1.080 mm.
    Max. workpiece swing diameter 1.050 mm.
    Max. workpiece height 1.300 mm.
    Pallet indexing time 20 s.
    Longitudinal Travel (X Axis) 1.050 mm
    Cross Travel (Y Axis 900 mm
    Vertical Travel (Z Axis) 1.030 mm
    Max. Working Feeds (X, Y, Z) 0-60 m/min
    Rapid Feeds (X, Y, Z) 60 m/min
    Head Turning Speeds 12.000 mm/min
    Taper BT-50
    Main Motor Power 55/30 kW
    Automatic Tool Charger INCLUDED
    ATC Type Cadena / Chain
    ATC Positions 60
    Changer Type Double Gripper.
    Tool Diameter 110 mm.
    Tool diameter with free adjacent tools 320 mm.
    Max Tool Length 630 mm.
    Tool Change Time 2.05 s.
    Internal Coolant supply 1.5 MPa INCLUDED
    Coolant Gun INCLUDED
    Portable SteeringWheel INCLUDED
    Chip Conveyor INCLUDED
    Oil Coolant INCLUDED
    Machine Weight 18.000 Kg.
    Machine Dimensions (L/W/H) 3.930 x 5.917x 3.300 mm.

    Detailed information of this Used Horizontal Machining Center

    Second Hand NHX-6300 DMG – MORI for sale at our used metalworking machinery warehouse in Zaragoza, Spain

    ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
    Technical specifications are not binding and may be modified without notice
