Used Gurutzpe A800x3000
Other available CNC Lathes
MORI SEIKI NT 4250-DCG 1500S
Second-hand turning and milling center New in 2008 with MSX-701 III CNC Spindle 1, spindle 2 and too spindle C axis in Spindle 1 and 2 Y Axis. Hydraulic steady rest SMW Autoblock
Mori Seiki NLX 2500SY/700
Mori Seiki turning center new in 2011 C axis in spindle and sub spindle. Y Axis Maximum swing over bed: 590 mm. Driven Tools. High precision refrigeration Bar feeder and part
Gurutzpe A 1000/3 x 4000
4 meter used Gurutzpe CNC Lathe New in 2003. CNC FAGOR 8055 Max swing over bed :800 mm. C Axis and driven tools Turret SAUTER VDI 50 12 positions Chip
Geminis GHT4 720X3000
New in 2004 with FAGOR 8055 TC/B Maximum swing over bed/cross slide: 720/470 mm. C axis and driven tools Sauter turret 8 positions SHW Autoblock 315 BH Self-Centering 3-Jaw Chuck Hydraulic
DAEWOO PUMA 2000-SY
New in 2003 with CNC FANUC 18i – T Max swing over bed/ carriage: 600/550 mm. Y Axis Travel: 100 (±50) mm. B Axis Travel: 580 mm. C axis 0.001º Driven turret positions
GEMINIS GHT5 G2 1000 x 9000
Manufactured in 2007 with CNC HEIDENHAIN 4110 MANUAL PLUS ØMax. turning over bed/carriage: 1,000/680 mm. C axis and driven tools VDI 50 turret (Ø 470 mm) with 8 positions Distance between
Technical Features of this Second Hand CNC Lathe
Max. Volteo sobre Bancada | 600 mm. |
Max. Volteo sobre Carro | 500 mm. |
Distancia entre centros | 3000 mm. |
Avance rápido Eje X | 6 m/min |
Avance rápido Eje Z | 6 m/min |
Revoluciones del Cabezal | 25-2800 |
Nº de Gamas | 2 Gamas. |
Potencia Motor Principal | 37 Kw. |
Inclinación Bancada | 30º |
Tipo de Nariz Cabezal | DIN-55026 |
Diámetro Interior del Husillo | 102mm. |
Peso Admisible sobre puntos | 2000 Kg. |
Peso Admisible sobre plato | 500 Kg. |
Torreta Automática | INCLUIDO |
Nº. Posiciones Torreta Automática | 12 Pos. |
Disco Portaherramientas | INCLUIDO |
Distancia entre caras | 500 mm. |
Contrapunto | INCLUIDO |
2 Luneta Hidráulica Autocentrantes | INCLUIDO |
CNC | FAGOR 8025 |
Diámetro Caña Contrapunto | 160 mm. |
Cono Morse del punto | 6 |
Peso de la Máquina | 13000 kg |
Año de Fabricación | 1994 |
Detailed information of this Second Hand CNC Lathe
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
Sold. Request information about this type of machinery
