Gurutzpe A 1600 2G x 6000

    6 meter Gurutzpe CNC Lathe
    Request information on similar machines

    Other available CNC Lathes

    CNC Lathe Mori Seiki NT4250-DCG

    MORI SEIKI NT 4250-DCG 1500S

    Second-hand turning and milling center New in 2008 with MSX-701 III CNC Spindle 1, spindle 2 and too spindle C axis in Spindle 1 and 2 Y Axis. Hydraulic steady rest SMW Autoblock

    Used Mori Seiki NLX2500700SY turning center for sale

    Mori Seiki NLX 2500SY/700

    Mori Seiki turning center new in 2011 C axis in spindle and sub spindle. Y Axis Maximum swing over bed: 590 mm. Driven Tools. High precision refrigeration Bar feeder and part

    GEMINIS GHT-5 G2 1000 X 9000 - Used

    GEMINIS GHT5 G2 1000 x 9000

    Manufactured in 2007 with CNC HEIDENHAIN 4110 MANUAL PLUS ØMax. turning over bed/carriage: 1,000/680 mm. C axis and driven tools VDI 50 turret (Ø 470 mm) with 8 positions Distance between

    Géminis GHT-4 720X3000

    Geminis GHT4 720X3000

    New in 2004 with FAGOR 8055 TC/B Maximum swing over bed/cross slide: 720/470 mm. C axis and driven tools Sauter turret 8 positions SHW Autoblock 315 BH Self-Centering 3-Jaw Chuck Hydraulic

    GEMINIS GHT5 G2 1000x4000

    GEMINIS GHT5-G2 1000×4000

    Used Geminis lathe with 4 meters between centers New in 2007 with CNC:FAGOR 8055 TC/C SAUTER turret 300×300 with 4 positions C axis and driven tools Equipped with tools and

    Gurutzpe A 1000 / 3 x 4000

    Gurutzpe A 1000/3 x 4000

    4 meter used  Gurutzpe CNC Lathe New in 2003. CNC FAGOR 8055 Max swing over bed :800 mm. C Axis and driven tools Turret SAUTER VDI 50 12 positions Chip

    Daewoo Puma CNC Lathe

    DAEWOO PUMA 2000-SY

    New in 2003 with CNC FANUC 18i – T Max swing over bed/ carriage:  600/550 mm. Y Axis Travel: 100 (±50) mm. B Axis Travel: 580 mm. C axis 0.001º Driven turret positions

    Technical Features of this Second Hand CNC Lathe

    Distance Between Centres 6.000 mm.
    Centre height 810 mm.
    Support Guides Number 2
    3 Hardened Guides INCLUDED
    Max. Ø Swing Over Bed 1.620 mm.
    Max. Turning Ø Cross Slide 1.220 mm.
    Rapid Traverse X Axis 10.000 mm/min
    Rapid Traverse Z Axis 10.000 mm/min
    Turning Speeds 20-800 rpm
    Head Automatic Range Number 2
    Main Engine Power 51 kW
    Spindle Maximum Torque 14.600 Nm
    Turret Station Number 4
    BARUFALDI TURRET 4 STATION 360 x 360 mm.
    Quill Spindles Cross 150 mm.
    Width Best 1.090 mm.
    Turning and drive tailstock with pressure regulation INCLUDED
    Quill Tailstock 220 mm.
    Turning point of the tailstock MORSE 6
    Machine dimensions 11.830 x 3.600 mm
    Chuck Protection INCLUDED
    Complete Rear Protection INCLUDED
    Chuck with 4 Indep. Hard Jaws Ø1500 mm INCLUDED
    Fix Steady Cap 50-500 INCLUDED
    Fix Steady Cap 500-900 INCLUDED
    Portable handwheel INCLUDED
    Support for boring bar Ø160 mm. INCLUDED
    Boring bar Ø 250 x 1.700 mm INCLUDED
    Boring bar Ø 160 x 2.000 mm INCLUDED
    Boring bar Ø 100 x 1000 mm INCLUDED
    C Axis and Dirven tool installation INCLUDED
    Driven tool NOT INCLUDED
    Max.Weight Between Centres 15.000 kg.
    Longitudinal Chip Conveyor INCLUDED
    Machine total power 68 kW.
    Machine Weight 26.000 kg

    Detailed information of this Second Hand CNC Lathe

    Second-hand Gurutzpe A 1600 2G x 6000 CNC lathe for sale. It has been completely reconditioned by our used CNC lathe experts and is ready for immediate delivery. It can be seen in operation at our used machine shopfloor in Zaragoza

    Are you interested in this rebuilt Gurutzpe A 1600 2G x 6000?

    Then don’t hesitate and contact us. Whether you just want to receive a no-obligation offer , you want to get furtherinformation or come see the machine in operation, we will be happy to help you.

    Call us at +34 976500624, write an email to sales@maquinariacolas.com or fill out the information request form. One of our experts in second-hand lathes will contact you and answer all your questions.

    ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
    Technical specifications are not binding and may be modified without notice
