Correa FP40/60 Bridge Type Milling Machine
Other available Bridge and Gantry milling machines
Nicolás Correa FP 50/80 5 axis
New in 2010 with CNC iTNC-530 5 axis Table: 8.500×2.500 mm. Travels (X/Y/Z) :8.000/3.800/1.250 mm Distance between columns: 3.100 mm 5-axis automatic head B/C axis oscillation range: ±
AWEA VP-2012
AWEA bridge type milling machine on liquidation sale New in 1998 with Siemens 810D CNC Table surface: 2,200 x 1,100 mm Travels (X/Y/Z) :2,000 /1,200/760 mm Distance between columns: 1,300
Zayer TEBAS 5000
New in 2013 with HEIDENHAIN iTNC-530 HSCI CNC. Automatic head 45º 0.001º/0.001º 6000 rpm 43 kW Direct output head reduction 1:2.29 Automatic head changer ATC 20 tools Chip conveyor-
Used Correa FP40/30 Bridge Type Milling Machine
Used Correa FP40/30 ATC UDG Bridge Type milling machine. CNC Heidenhain TNC 426. Orthogonal Autoindex Head 2.5º/2.5º. Internal Coolant. ATC 10 Tools.
Nicolás Correa FP40-40
Manufactured in 1997 with HEIDENHAIN TNC 426M Table: :4,000 x 1,250 mm Travels (X/Y/Z) :3,500/2,500/1,000 mm Distance between columns: 2,300 mm Direct head and 45º head Chip
Correa RAPID-50
New in 2005 with CNC FIDIA C20 (Heidenhain TNC 530 optional) Table surface: 5,000 x 2,000 mm Travels (X/Y/Z): 5,000/3,100/1,200 mm Distance between columns: 2,800 mm. Automatic head UAD II
Technical Features of this Brige Type Milling Machine
| New in | 1996 |
| Refurbished in | 2019 |
| CNC | Heidenhain TNC 530 |
| Table Surface | 6.000 X 2.000 mm |
| Travels (X/Y/Z) | 6.000 /3.000/ 1.000 mm |
| Distance Between Columns | 2.520 mm |
| Rapid Feed (X Axis) | 15.000 mm/min |
| Rapid Feed (Y,Z Axis) | 12.000 mm/min |
| Max. Working Feed | 5.000 mm/min |
| Direct Output Head | INCLUDED |
| Universal Head 45º | INCLUDED |
| Auto Indexing Head | 2,5º |
| Taper | ISO-50 |
| Speed Direct Output Head | 5.000 r.p.m. |
| Speed Head 45º | 3.000 r.p.m. |
| Main Engine Power | 30 Kw. |
| Speed Range | 2 Ranges |
| Automatic Tool Charger | INCLUDED |
| Tools al Tool Charger | 60 |
| Max Allowed Weight on Table | 25.000 Kg. |
| Machine Weight | 48.000 Kg. |
| Retractable Manual Support in the | |
| Right Side for Head 45º | INCLUDED |
| Portable Handwheel | HEIDENHAIN HR-410 |
Detailed information of this Brige Type Milling Machine
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
