CMZ TA20Y 640 CNC Lathe
Other available CNC Lathes
Geminis GHT4 720X3000
New in 2004 with FAGOR 8055 TC/B Maximum swing over bed/cross slide: 720/470 mm. C axis and driven tools Sauter turret 8 positions SHW Autoblock 315 BH Self-Centering 3-Jaw Chuck Hydraulic
GEMINIS GHT5 G2 1000 x 9000
Manufactured in 2007 with CNC HEIDENHAIN 4110 MANUAL PLUS ØMax. turning over bed/carriage: 1,000/680 mm. C axis and driven tools VDI 50 turret (Ø 470 mm) with 8 positions Distance between
DAEWOO PUMA 2000-SY
New in 2003 with CNC FANUC 18i – T Max swing over bed/ carriage: 600/550 mm. Y Axis Travel: 100 (±50) mm. B Axis Travel: 580 mm. C axis 0.001º Driven turret positions
Gurutzpe A 1000/3 x 4000
4 meter used Gurutzpe CNC Lathe New in 2003. CNC FAGOR 8055 Max swing over bed :800 mm. C Axis and driven tools Turret SAUTER VDI 50 12 positions Chip
MORI SEIKI NT 4250-DCG 1500S
Second-hand turning and milling center New in 2008 with MSX-701 III CNC Spindle 1, spindle 2 and too spindle C axis in Spindle 1 and 2 Y Axis. Hydraulic steady rest SMW Autoblock
Mori Seiki NLX 2500SY/700
Mori Seiki turning center new in 2011 C axis in spindle and sub spindle. Y Axis Maximum swing over bed: 590 mm. Driven Tools. High precision refrigeration Bar feeder and part
Technical Features of this Second Hand CNC Lathe
| New in | 2015 |
| CNC | FANUC 32i 15" |
| C Axis and Driven Tools | INCLUDED |
| Y Axis | INCLUDED |
| Distance Between Centres | 713 mm. |
| Ø Swing over Bed | 750 mm. |
| Ø Max. Turning | 460 mm. |
| Ø Max.Turning over Carriage | 600 mm |
| X Travel | 310 mm. |
| Z Travel | 640 mm. |
| Y Travel | +70 -50 |
| B Travel | 640 mm. |
| Rapid Feeds (X, Z Axis) | 30 m/min. |
| Rapid Feed (Y Axis) | 15 m/min. |
| Rapid Feed ( B Axis) | 11 m/min. |
| Max Speed of the Head | 4.000 rpm |
| Ø Quill | 66 mm. |
| Chuck Ø | 210 mm. |
| Tailstock Taper | CM5 |
| Turrent Positions | 12 |
| Diven Tools Positions | 12 |
| Driven Tools Speed | 12.000 rpm |
| Driven Tools Max. Power 11,3 | Kw |
| Internal Coolant 20 Bar | INCLUDED |
| Autoblock Chuck BBD-210 | INCLUDED |
| Presetter | INCLUDED |
| Side Chip Conveyor | INCLUDED |
| 2 Radial Driven Toolholders | INCLUDED |
| 2 Axial Driven Toolholders | INCLUDED |
| Capacity Side Coolant Tank | 230 l. |
| Capacity Rear Coolant Tank | 200 l. |
| Capacity Hydraulic Oil Tank | 10 l. |
| Capacity Lubricant Tank | 4 l. |
| Total Installed Power | 30 KVA |
| Machine Weight | 5.900 Kg. |
| Machine Dimensions | 2.542×1.760×2120 mm. |
Detailed information of this Second Hand CNC Lathe
This second-hand CMZ TA20Y 640 Lathe is in stock. Has been revised and ready for inmediate delivery. It can be seen under power in our warehouse in Zaragoza; a space of more than 12,000 m2 of permanent exhibition of second-hand machine tools of the highest performance and with the best quality / price ratio.
It is a CNC lathe with C axis, driven tools and Y axis. It was manufactured in 2015 with a 15″ Fanuc 32i CNC.
Do you want to know more about this CMZ TA20Y 640 lathe?
Don’t hesitate and contact us. We will send you all the information you need about this second-hand CMZ lathe as well as a not binding budget.
You can call us at 976500624, write to us at sales@maquinariacolas.com or fill out the form at the bottom of this page.
If you prefer to come and visit us to see the machine under power, contact us. We will coordinate with you the date / time for the visit that best suits you.
We need to make an appointment in advance to be able to serve you as you deserve. Before your arrival, our technicians will put the machine into operation and a commercial technician will be at your disposal throughout the visit.
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
