Gurutzpe A1000 4G x 5.000
Technical Features of this Second Hand CNC Lathe
| Fabricante | GURUTZPE |
| Modelo | A-1000 4G X 5.000 |
| Año | 2003 |
| CNC | SIEMENS SINUMERIK 840 D |
| Capacidades y avances | |
| Altura de centros | 450 mm. |
| Distancia entre puntos | 5.000 mm. |
| Recorrido carro transversal | 530 mm. |
| Recorrido carro longitudinal | 5.000 mm. |
| 3º guía de apoyo para el carro | INCLUIDO |
| Volteo máximo sobre bancada | 900 mm. |
| Volteo máximo sobre carro transversal | 650 mm. |
| Anchura bancada | 970 mm |
| Avance rápido ejes X / Z | 10 m/min |
| Cabezal | |
| Revoluciones del cabezal | 0-1.600 rpm |
| Nº de gamas automáticas de cabezal | 2 |
| Potencia motor principal | 28/34 kW |
| Paso de barra de cabezal | 105 mm. |
| Torreta | |
| Tipo torreta | SAUTER 0.5.320.025 |
| Posiciones torreta | 4 |
| Tamaño herramientas | 280×280 mm. |
| Contrapunto | |
| Diámetro de la caña del contrapunto | 140 mm. |
| Eje W – contrapunto motorizado controlado por CNC | INCLUIDO |
| Equipamiento adicional | |
| Puerta delantera | INCLUIDO |
| Protección de plato | INCLUIDO |
| Protección trasera completa | INCLUIDO |
| Plato 4 garras independientes Ø 600mm | INCLUIDO |
| Luneta hidráulica SHW Autoblock SLU-5-ZS con capacidad 45-310 mm. | INCLUIDO |
| Luneta fija “tipo C” Ø250 mm | INCLUIDO |
| Eje V movimiento CNC longitudinal eje Z para luneta SHW Autoblock | INCLUIDO |
| Luneta tipo cabezal con plato 4 garras independientes Ø 500 / paso barra 250 mm | INCLUIDO |
| Aire acondicionado en armario eléctrico | INCLUIDO |
| Evacuador de virutas longitudinal | INCLUIDO |
| Soporte para barra de mandrinado | INCLUIDO |
| Otros | |
| Potencia total | 58 kW |
| Peso de la máquina | 20.000 kg. |
| Dimensiones de máquina | 11.125×3.285×2.120 mm |
Detailed information of this Second Hand CNC Lathe
Used Gurutzpe A1000 4G x 5000 CNC lathe for sale. It’s been refurbished by our team of used machine tool experts and is located at our warehouse in Zaragoza, ready for immediate delivery, where it can be seen in operation.
Manufactured in 2003 with Siemens Sinumerik 840D CNC control, this horizontal CNC lathe is designed to offer maximum precision, structural stability, and high performance in demanding industrial applications. It is ideal for sectors such as energy, oil and gas, and the manufacture of shafts, cylinders, industrial rotary machines, and large components.
It is very well equipped with, among others:
- 4-position SAUTER turret
CNC-controlled driven tailstock (W-axis)
Independent 4-jaw chuck Ø600 mm
SHW Autoblock SLU-5-ZS hydraulic steady rest (45–310 mm)
Fixed steady rest Ø250 mm
Headstand steady rest with 4-jaw chuck Ø500 mm (250 mm bar capacity)
CNC drive for SHW Autoblock steady rest (V-axis)
Longitudinal chip conveyor
Air conditioning in electrical cabinet
Complete protection guards
Boring bar support
This combination makes the Gurutzpe A1000 4G x 5000 an ideal solution for heavy turning operations where reliability, durability, and excellent repeatability are essential.
Are you looking for an used Gurutzpe lathe with 5-meter distance between centers?
Then look no further. If you’re looking for a reliable CNC lathe for machining long workpieces, with a rigid bed, powerful headstock, and a full complement of steady rests and accessories, this model offers exceptional value. It’s the perfect machine for companies that require productivity, stability, and precision when machining large-format parts.
Call us at+34976500624, email us at sales@maquinariacolas.com, or fill out the information and quote request form. Whether you simply want to know the price of this used Gurutzpe A1000 4G x 5000, request more information, or come to see the machine in operation, we’ll be happy to help you.
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
